Requirement review
Drawing revision, material grade, application, critical dimensions and document needs are identified before quotation.
QUALITY CONTROL
Quality requirements defined before production.
Inspection scope is matched to the drawing, material, application and procurement requirements. Checkpoints and required records can be agreed before an order enters production.
CONTROL PATH
Four checkpoints from requirement to release.
Final inspection requirements depend on the part and purchase specification.
Material and process control
Material identity, production route, heat treatment and traceability requirements are defined for the project.
In-process inspection
Dimensions, hardness, appearance and specified process checkpoints are recorded according to the agreed plan.
Final release
Quantity, marking, packing and required inspection documents are checked before shipment release.
INSPECTION SCOPE
Define the evidence your procurement team needs.
Not every project requires the same inspection package. The applicable checks, acceptance criteria and document list should be confirmed against the drawing and order requirements.
Control itemReview focusPossible record
Material identityGrade, heat or batch referenceMaterial certificate when agreed
DimensionsCritical dimensions and tolerancesDimensional inspection report
HardnessSpecified range and test locationHardness inspection record
Surface and appearanceCasting condition and finish criteriaVisual inspection record
Additional testingNDT or third-party inspection if specifiedReport defined by the order
Shipment releaseQuantity, marking and packingFinal checklist and packing photos
PROJECT DOCUMENTATION
Records organized around the approved requirement.
Document availability and format are confirmed project by project before production.
Approved inputs
Drawing revision, material specification, inspection points and packing requirements.
Process records
Lot identification and agreed manufacturing or heat-treatment records where applicable.
Release evidence
Required dimensional, hardness, visual and quantity checks before packing.
Additional support
Material certificates, third-party inspection and other documents agreed in the order.
